ZWSim-EM 2022 SP3

Free Download ZWSim-EM full version standalone offline installer for Windows. It is a 3D Full-Wave Electromagnetic Simulator.

Overview of ZWSim-EM

This is CAE simulation software independently owned by ZWSoft. It includes general pre-and post-processing functions, integrates structural simulation, electromagnetic simulation, fluid simulation solver (secondary development demo), and supports multi-disciplinary simulation.

It is an essential milestone for ZWSOFT’s all-in-one CAx strategy, aiming to satisfy users’ whole-process needs from designing and simulating to manufacturing and constructing. The newly added FEM algorithm and complete pre-and post-processing capabilities come with a significant highlight.

It can simulate high-precision geometries and electrically small and delicate structures, like high-frequency array antennas, helical antennas, coaxial connectors, high-speed connectors, etc., broadening the application range and satisfying more EM simulation needs.

Features of ZWSim-EM

• Embedded Integral Technique
• Finite Element Method
• Easy to use with a friendly user interface
• Fully Compatible with Native CAD Models
• Powerful 3D Modeling and Modifying
• Faster Simulation-Driven Design
• Customizable Materials
• Parameter Sweep
• Multiple Array Patterns
• Multiple Boundaries and Excitation Source
• Post-Processing Results Displayed in Various Ways
• Export Detailed Simulation Reports

Technical Details and System Requirements

• Supported OS: Windows 11 / Windows 10 / Windows 8.1
• CPU: Intel Core 2 Duo or AMD Athlon X2 CPU or higher (recommended)
• RAM: 4GB (8GB or more recommended)
• Free Hard Disk Space: 2GB or more recommended
• Resolution: 1024 x 768VGA display with True Color (minimum) 1440x900 with NVidia 8 series or Radeon HD series or higher
