Optenni Lab 4.3 SP5


Free Download Optenni Lab 4 full version standalone offline installer for Windows it is a specialized software designed for the automatic synthesis of the coordination circuits of microwave devices.

You can also FREE download Battery Optimizer

Overview of Optenni Lab 4 Benefits

Evaluating the maximum achievable operating frequency band of antennas and calculating the worst case isolation between several antennas in the system. Matching chains can include both concentrated and distributed elements.

As concentrated elements, components from a special database can be used, taking into account the tolerance on the spread of parameters.

Overview of Optenni Lab 4 Features

  • Matching circuit synthesis: Optenni Lab’s automatic matching circuit synthesis provides the user with multiple optimized topologies using fast parallelized multicore optimization techniques. The synthesis applies to both single-port and multiport RF systems.
  • Optimization using component library: Optenni Lab optimizes the matching circuits using component models from leading inductor and capacitor manufacturers, taking into account component losses, parasitic effects and component tolerances.
  • Tolerance analysis: The sensitivity of various topologies to component tolerances is readily analyzed by Optenni Lab's tolerance analysis feature. Different available tolerance variants of the library components can be chosen for the analysis.
  • Tunable antenna design: Optenni Lab supports tunable antenna design, where the target bands are switched by a network of fixed and variable components - either realized by switches or dedicated tuner components.
  • Multi-antenna matching: It supports multi-antenna matching for best efficiency, taking antenna-to-antenna coupling into account. The optimization setup enables control of both efficiency and isolation.
  • Advanced impedance analysis tools: Optenni Lab provides advanced analysis tools, such as the bandwidth potential and electromagnetic isolation calculations for evaluation and ranking of antenna concepts and prototypes.
  • Radiation efficiency calculation: Optenni Lab supports frequency-dependent radiation efficiency data in optimization of the total efficiency of the antenna.

Technical Details and System Requirements

  • Supported OS: Windows 7/8/10
  • Processor: Pentium IV or higher
  • RAM: 1 GB RAM (2 GB recommended)
  • Free Hard Disk Space: 500 MB or more
