Free Download NUMECA FINE Marine 9 for Windows PC it is an integrated CFD software environment for the simulation of mono-fluid and multi-fluid flows around any kind of ships, boats or yachts, including various types of appendages.
You can also FREE download AVEVA Marine - Marine Engineering Software
Overview of NUMECA FINE Marine 9 Benefits
A powerful, customized graphical user interface, with integrated marine-dedicated features, for the simulation of mono-fluid and multi-fluid flows around any kind of ship, boat or yacht, including various types of appendages.
Drastically reduce the engineering time for the complete CFD simulations set-up. Don’t spend time on setting numerical parameters: get the job done immediately. In this program 6DOF incompressible flowsolver works for all types of marine applications, including free surface capturing.
Thanks to the Rhino plug-in for FINE/Marine export your CAD model from the Rhinoceros interface directly to C-Wizard or to our meshing environment, hasslefree.
Overview of NUMECA FINE Marine 9 Features
- Non-conformal, fully hexahedral meshes
- Viscous layers insertion with inflation method
- Thin surfaces modeling (sails, trim tabs…)
- Replace geometries module
- Limited user inputs – high degree of automation
- Fully scriptable
- Highly accurate free surface capturing
- 6DOF with marine dedicated motion laws
- Quasi static approach for all kinds of boats and hydrofoils
- Sub cycling acceleration
- Adaptive grid refinement
- Sliding grid interfaces
- Overlapping grid
- Cavitation modeling
- Mooring and tugging line
- User defined dynamic libraries (forces and motions)
- Marine dedicated environment
- Fully scriptable
- Wizard for mesh and computation setup
- Marine dedicated add-ons
- Fully scriptable
Technical Details and System Requirements
- Supported OS: Windows 7/8/10 (64-bit)
- Processor: Multi-processor, multi-core PC
- RAM: 2 GB RAM
- Free Hard Disk Space: 2 GB or more
