Free Download LimitState RING Full Version - Latest Offline Installer - The industry-leading software application.


Free Download LimitState RING full version standalone offline installer for Windows. It is an industry Leading Masonry Arch Bridge Analysis Software.

Overview of LimitState RING

It is an industry-leading masonry arch bridge analysis software. It is trusted by central consulting engineers, bridge owners, and universities worldwide, an industry-leading software application for rapid masonry arch analysis. For a quick and easy single-span highway or railway arch bridge analysis.

The Problems can contain stone voussoir or brickwork arch barrels, bonded or multi-ring. A range of predefined and user-defined arch profiles are available. It was developed in association with the International Union of Railways (UIC) and ships with a database of rail vehicles. Axle loads are distributed through track/sleepers by industry practice.

It provides a powerful diagnostic tool for investigating the causes of observed cracks and the behavior of masonry arch bridges under service loads.

Features of LimitState RING

  • The easy-to-use interface enables a bridge model with vehicle loading to be created in minutes.
  • Rigorous optimization is used to find the critical mode of response and margin of safety
  • Allows masonry arch bridges incorporating reinforcement to be modeled
  • Developed by acknowledged experts in the field and validated against laboratory and field bridge tests
  • Single-span arch or complex multi-ring, multi-span viaduct
  • Analysis results typically available in seconds

Technical Details and System Requirements

  • Supported OS: Windows 11, Windows 10, Windows 8.1, Windows 7
  • RAM (Memory): 2 GB RAM (4 GB recommended)
  • Free Hard Disk Space: 400 MB or more

Previous version

Additional info
File Name:LimitState RING (x64)
File Name:LimitState RING 3.2.c.24386 (x64)
