Guthrie HPGL2CAD 2020 A.10

Free Download Guthrie HPGL2CAD 2020 full version standalone offline installer for Windows, it is used to instantly convert HPGL & HP-GL/2 .plt files to DWG / DXF.

You can also FREE download DryLab System

Overview of Guthrie HPGL2CAD 2020

This is a lightweight and efficient piece of software that allows you to quickly convert HPGL, HP-GL, and PLT files to DWG and DXF, both formats that are supported by a multitude of CAD applications out there.

Before anything else, you should be aware of the fact that this application is capable of outputting files compatible with all version of AutoCAD, starting from AutoCAD 11, 12, 13, and 14, all the way up to AutoCAD 2016.

Deploying this utility on your computer's system is by no means challenging, thanks to a streamlined installer that does not require much user intervention in order to get the job done.

Features of Guthrie HPGL2CAD 2020

  • Batch conversion on the software interface.
  • Batch conversion via command line.
  • Allows wild card file naming to be used - i.e. translate *.plt *.dxf or *.plt *.dwg etc.
  • Command Line mode allows automated conversions.
  • Support multi-folio (multi-page) plot files. Each page is output to a separate DXF/DWG file.
  • Efficient output. e.g. makes use of R14+ DXF/DWG HATCH entity instead of outputting multiple lines.
  • Option to join lines and arcs to single polyline.
  • Output HPGL 'dot' as Point, or ignore, in preference to the HP defined 'unit length vector'.

Technical Details and System Requirements

  • Supported OS: Windows 7/8/10
  • Processor: Pentium IV or higher
  • RAM: 1 GB RAM (2 GB recommended)
  • Free Hard Disk Space: 200 MB or more

Previous version

Additional info
File Name:Guthrie HPGL2CAD 2020 A.08
Version:2020 A.08
