Software Companions Gerbview 9.10

Free Download Software Companions Gerbview (32-bit/64-bit) full version standalone offline installer for Windows. It is an application that packs all the necessary features for helping you view, print, and markup Gerber, HPGL, and EXcellon files.

You can also FREE download PhotoDiva.

Overview of Gerbview Benefits

The app sports a user-friendly interface and a clean layout that allows users to perform several actions on the go. You can drag and drop the documents directly into the main window or add them by browse function. Hotkeys are also available, and they can be reassigned.

It is possible to create a workspace that can include multiple files. The workspace can be exported or imported, provided that the file format is GBW. Not only does the program help you open and check out the content of your documents, but it also provides some editing tools, such as arrows, lines, images, ellipses, and polygons.

You can even add text and images to your documents and save the workspace to a separate file. Provides you with many useful features for viewing and printing Gerber, HPGL, and EXcellon files.

Overview of Gerbview Features

  • View, print, markup and convert Gerber, HPGL/2, Excellon and raster formats.
  • Convert Gerber, Excellon and HPGL/2 files to AutoDesk DXF, Adobe PDF and other formats.
  • Convert multiple Gerber files to a multi layer PDF, DWF or DXF file.
  • Query for entity information in Gerber, HPGL/2 and Excellon files.
  • Measure distances, areas and perimeters, with our without snapping to pads and tracks.
  • Both metric and imperial coordinates supported.
  • Support for absolute or relative coordinates.
  • Highlight selected apertures in Gerber files.
  • Add files of different formats to a single workspace.

Technical Details and System Requirements

  • Supported OS: Windows 10, Windows 8.1, Windows 7
  • RAM (Memory): 2 GB RAM (4 GB recommended)
  • Free Hard Disk Space: 200 MB or more
