Free Download Bridge Software Institute FB-MultiPier 5.6.0 Full Version - Latest Offline Installer - Analyze multiple bridge pier structures .

Free Download Bridge Software Institute FB-MultiPier full version standalone offline installer for Windows it is a nonlinear finite element analysis program capable of analyzing multiple bridge pier structures interconnected by bridge spans.

You can also FREE download ARES Commander

Overview of Bridge Software Institute FB-MultiPier Benefits

The full structure can be subject to a full array of AASHTO load types in a static analysis or time varying load functions in a dynamic analysis. Each pier structure is composed of pier columns and a cap. This structure is supported on a pile cap and piles/shafts with nonlinear soil.

This analysis program couples nonlinear structural finite element analysis with nonlinear static soil models for axial, lateral and torsional soil behavior to provide a robust system of analysis for coupled bridge pier structures and foundation systems. FB-MultiPier performs the generation of the finite element model internally given the geometric definition of the structure and foundation system as input graphically by the designer.

This allows the engineer to work directly with the design parameters and lessens the bookkeeping necessary to create and interpret a model. As is a necessity for design-oriented applications, FB-MultiPier automatically generates finite element models given a parametric, geometric definition of the structure and foundation system. Both input and analysis results are handled through a streamlined combination of form-based, 2D graphics, and 3D graphics windows.

Technical Details and System Requirements

  • Supported OS: Windows 10 / Windows 8.1 /Windows 7
  • Processor: Multi core Intel Series or above, Xeon or AMD equivalent
  • RAM: 4GB (8GB or more recommended)
  • Free Hard Disk Space: 4GB or more recommended
