Free Download Ensoft Group for Windows PC. It is a renowned software for analyzing pile group behavior under combined axial, lateral, and torsional loadings. It offers a comprehensive solution for computing load distributions, estimating lateral and axial movements of piles and caps, and ensuring compatibility of deformations and equilibrium of forces within the group model.

Overview of Ensoft Group

It is a powerful tool developed to handle the complexities of pile group analysis. It employs advanced algorithms to compute the distribution of loads applied from multiple locations in a pile cap to piles arranged in a group. The program also generates nonlinear responses of the soil, including t-z and Q-w curves for axial loading, p-y curves for lateral loading, and T-q curves for torsional loading.

Pile Sections

It supports various pile sections to accommodate different project requirements:

  • User-defined piles with circular, rectangular, and wide-flange sections.
  • Option to include nonlinear flexural stiffness for standard reinforced concrete or complex composite sections with structural steel inserts.
  • Predefined AISC sections from a built-in library.
  • User-defined sectional properties for customization.


It accepts combined loadings with load factors and computes maximum and minimum envelopes for load cases and combinations. Users can specify concentrated loads at the pile cap or distributed lateral loads along any pile(s) length. It also includes an option to use a cyclic model for soil p-y curves.

Soil Movement

Users can input a profile of soil movements versus depth as additional loading on the pile. These soil movements may result from various actions such as slope instability, lateral spreading during earthquakes, and seepage forces.

System Requirements

  • Operating System: Windows 11/10/8.1/8/7
  • Processor: Minimum 1 GHz Processor (2.4 GHz recommended)
  • RAM: 2GB (4GB or more recommended)
  • Free Hard Disk Space: 4GB or more is recommended


Ensoft Group offers a robust solution for analyzing pile group behavior under complex loadings. Its advanced features and user-friendly interface provide engineers and researchers with the tools they need to ensure the structural integrity and stability of pile foundations. Whether designing new structures or assessing existing ones, Ensoft Group delivers reliable results and enhances the efficiency of pile group analysis.
