DS Simulia XFlow 2020x Build 110.08

Free Download Dassault Systemes DS Simulia Xflow 2020 for Windows PC and Linux this state-of-the-art technology enables users to address complex CFD problems involving high frequency transient aerodynamics, real moving geometries, complex multiphase flows, fluid structure interactions and aero acoustics.

You can also FREE download Dassault Systemes DS SIMULIA Suite

Overview of DS Simulia Xflow 2020 Benefits

XFlow offers particle-based Lattice-Boltzmann technology for high fidelity Computational Fluid Dynamics (CFD) applications expanding SIMULIA’s CFD portfolio. XFlow’s state-of-the-art technology enables users to address complex CFD workflows involving high frequency transient aerodynamics with real moving geometries, complex multiphase flows, free surface flows and fluid-structure interactions.

XFlow’s automatic lattice generation and adaptive refinement capabilities minimize user inputs thereby reducing time and effort in the meshing and pre-processing phase of a typical CFD workflow. This enables engineers to focus the majority of their efforts on design iteration and optimization, rather than the time consuming meshing process.

With XFlow’s discretization approach, surface complexity is also not a limiting factor. The underlying lattice can be controlled with a small set of parameters; the lattice is tolerant to the quality of the input geometry and adapts to the presence of moving parts.

In addition, advanced rendering capabilities provide realistic visualization to gain deeper insight into flow and thermal performance. XFlow’s unique capabilities enable companies to reduce physical testing while making to make better design decisions faster.

Overview of DS Simulia Xflow 2020 Features

  • Co-simulations with Abaqus
  • Co-simulation with Simpack via FMI standard
  • Direct support of CATIA parts
  • CST-XFlow one-way coupling
  • Multiphase Volume of Fluid (VoF) solver
  • Animated geometry behavior for simplified FSI analysis
  • New thermal boundary conditions
  • Mutual exchange of information automatically performed by the Co-simulation Engine

System Requirements and Technical Details

  • Supported OS: Windows 7/8/10 (64bit)
  • Processor: Quad Core or Dual Hexa Core i7 processors
  • RAM: 12 GB RAM (24 GB recommended)
  • Free Hard Disk Space: 5 GB or more
