Free Download BobCAD-CAM for Windows PC. It is a comprehensive CAD-CAM software that empowers users with powerful tools for designing and programming parts efficiently.

Overview of BobCAD-CAM

It has introduced significant enhancements, particularly in geometry selection and program editing. This is also a versatile Toolpath Editor, giving users unprecedented control over their operations.

Lead From Center

By default, the Lead from Center option allows you to utilize the centermost positions of the created toolpath chains. In the past, creating leads that started/ended in the center of the chain could be a little more challenging than you would initially think. Customers requesting the ability to do this easily led to these new lead types. There is no need to measure areas and calculate leads as these leads work on any shape to find the center-most point created by the chains.

Conical Machining

When we came out with our 4 Axis Advanced Rough and 4 Axis Advanced Finish operations, it helped a lot in machining those shapes, but the toolpath wasn't specialized for those shapes, and there were still some drawbacks. Everything from the step-downs to the limits is designed for cylindrical shapes. That meant conical floors would have steps, and air cutting on the smaller end was impossible to remove with radial limits. These issues are now a thing of the past with the new Conical Machining option. Select the check box on the Patterns page, set the Cone Angle, and now the entire toolpath is designed for that exact shape.

New Deburring Toolpath

While the Deburring operation has always offered ways to specify the area to focus on by allowing the selection of specific edges, checking surfaces to avoid, and limiting the area by height, deburring only specific areas meant a lot of geometry selections and even adjustment of the operation settings. Now, hitting exactly what needs to be hit has never been easier. Select a solid or solid from the graphics area; only the area inside these solids will have the Deburring toolpath applied.

New CAM Tree Enhancements

The Machining order dialog has been replaced by a complete Operation Tree, which enhances the workflow in the software in many ways that were never possible. Once you've created your jobs in the CAM Tree, open the Tool Tree to see all your jobs, the tools in their tool crib, and which operations are assigned to each tool. For the first time, Mill and Lathe's jobs also support MDI, or manual data input, allowing you to define machine movement as needed for your machining operations manually.

Surface Based Toolpaths

Another tilting option is added to the arsenal of the Surface toolpath types with the new Tilted with a fixed angle to surface normal option. The proper tool tilt is important in multi-axis machining, and while we have many options to choose from, including staying fixed to the surface normal, in the past, you have not been able to adjust the tilt based on the surface normal. You can select the option, choose your reference surface, and set your angles.

5 Axis Milling

The Undercut option in the Options page of the Advanced Z Level Finish now allows you to do undercutting when the operation is set to 5 Axis in the Tool Axis Control page. While the undercutting option has been a huge help when using undercutting tools in a 3-axis operation, the undercut option has been unavailable when setting the operation to 5-axis. When set to 5 Axis, you can use Undercut with spherical tools by selecting one of the Checks on the Gouge Check page and setting the Strategy to Tilt tool. You can even set an Extend undercut area value to control how much is machined fully.

System Requirements

Operating System: Windows 10/11 x64
CPU: 2.0 GHz multi-core processor or higher
Memory: 6 GB RAM or higher
Available Hard Disk Storage: 2 GB or higher
Video: 1 GB graphics card that supports OpenGL 1.1

Conclusion

BobCAD-CAM is valuable for CAD-CAM enthusiasts. With enhanced geometry selection, program editing capabilities, and the addition of a versatile Toolpath Editor, users now have unprecedented control over their operations. The Scale Sketch Handle feature further adds precision and ease of use. It is worth considering if you're looking for powerful CAD-CAM software.

BobCAD-CAM 36 build 5032
