Free Download ASDIP Steel for Windows PC. This powerful tool is your ticket to efficiently designing steel base plates, steel and composite beams, steel columns, shear connections, anchor rods, and shear lugs. With this tool, you can confidently tackle complex steel design projects while adhering to the latest industry standards.

Overview of ASDIP Steel

It is engineered to simplify and streamline the structural design process. It is meticulously crafted to meet the requirements of AISC specifications, including AISC 360 and AISC 341 Seismic, as well as CSA S16-19. Whether you're working on a skyscraper, a bridge, or a steel structure, it has you covered.

Let's explore the key benefits and features that make it an indispensable tool for structural engineers.

Key Benefits of the Software

  • Efficient Modeling: Its intuitive graphical user interface lets you model your steel members quickly. Say goodbye to tedious calculations and welcome a user-friendly experience that saves you time and effort.
  • Code Compliance: Compliance with design code provisions is non-negotiable in structural engineering. The software ensures that your designs meet the latest industry standards, providing peace of mind and the confidence to proceed.
  • Professional Reports: Impress your clients and plan-checkers with professional reports. Depending on your project's requirements, these reports can be tailored to be condensed or detailed.
  • Extensive Resources: It doesn't just stop at software. It offers extensive documentation, solved examples, and blog posts to guide you throughout your structural design journey. It's like having a mentor at your fingertips.
  • Calculation Management: Keep your electronic calculations organized, accessible, and safe with the software. No more digging through stacks of paper or endless folders on your computer. Everything you need is neatly stored within the software.

Key Features of the Software

  • Base Plates and Anchorage: Whether dealing with axial or biaxial bending loads, including uplift, it has the tools to help you design robust base plates and anchorage systems.
  • Steel Columns: Designing steel columns is a breeze with this tool. Create structures that can withstand the test of time and the forces of nature.
  • Steel or Composite Beams: This software covers various beam design scenarios, from pure steel to composite ones.
  • Shear Connections: It handles shear connections elegantly, including single or double angles, single plates, or tees, with options for both bolted and welded connections.
  • Moment Connections: For moments that matter, use this tool to design flange-plated and welded-flange connections, available in bolted and welded configurations.
  • Customizable Design Criteria: Tailor your design criteria to meet specific project requirements. Adjust camber, deflections, and shear studs to match your needs.
  • Design Manager: The Design Manager feature is a true time-saver. It automatically identifies all steel sections that meet your design criteria, simplifying the selection process.

System Requirements

  • Operating System: Windows 7/8/10/11
  • Processor: Dual-core processor (Quad-core recommended)
  • RAM: 4 GB (8 GB recommended)
  • Hard Drive Space: 2 GB of free space
  • Graphics Card: DirectX 9-compatible graphics card (DirectX 11 recommended)


ASDIP Steel is a game-changer in the world of structural engineering. It empowers engineers to tackle complex steel design projects confidently, efficiently, and precisely. Adhering to the latest industry standards and offering a user-friendly interface has become indispensable for structural engineers worldwide.

Previous version

Additional info
File Name:ASDIP Steel
