Aarhus Workbench 6.7

Free Download Aarhus Workbench full version standalone offline installer for Windows. It is a unique and comprehensive software package for processing, inversion, and visualization of geophysical and geological data.

Overview of Aarhus Workbench

It is a unique and comprehensive software package for processing, inversion, and visualization of geophysical and geological data. The package integrates all steps in the workflow, from handling the raw data to the final visualization and interpretation of the inversion models.

This package includes dedicated data processing modules for many geophysical data types and an integrated GIS platform. It uses robust and fast inversion code. Visualization, evaluation, and geological interpretation of the inversion results are done with the GIS interface,

It is integrated with the processing tool and cross-sections. is fully compatible with ArcGIS formats (GeoTiff, Shape-files) and Surfer grid file format. Section location by drawing directly in the GIS map or based on survey flight lines.

Its Resistivity models are displayed as bars or interpolated filled sections, combined with the depth of investigation information. Boreholes as bars with easy access to detailed borehole reports. Digitization of layer interfaces for accessible geological model building.

Sections combined with intersections in a grid are displayed as lines. Extended label options for resistivity bars and boreholes, e.g., projection distances, lithology, etc.

Features of Aarhus Workbench

• Supports electrical and electromagnetic data from both airborne and ground-based systems
• Fully developed processing tools and filters
• Support for digital elevation models
• Support for import of borehole lithology and geophysical borehole logs
• Integrated GIS interface with WMTS support for easier processing and visualization
• Visualization of data in themes, sections, and 3D.
• Quality control visualization tool
• LCI and SCI inversion with AarhusInv inversion code
• 1D/2D ERT/IP inversion with AarhusInv inversion code
• Full ERT/IP decay inversion with Cole-Cole & Maximum Phase Angle inversion
• TEM IP Cole-Cole & Maximum Phase Angle inversion for modeling of TEM data with IP effects
• Cloud inversion
• 2D/3D gridding

Technical Details and System Requirements

• Supported OS: Windows 11, Windows 10, Windows 8.1, Windows 7
• RAM (Memory): 2 GB RAM (4 GB recommended)
• Free Hard Disk Space: 800 MB or more
