Droid Tesla Pro v6.21 APK Free Download - FileCR

Free Download Droid Tesla Pro v6.21 MOD Version Unlocked Ad-Free APK for Android Smartphones and Tablets.

Free Download Droid Tesla Pro MOD Version Unlocked Ad-Free APK for Android Phones and Tablets. It is a simple and powerful circuit simulator.

Overview of Droid Tesla Pro APK for Android

This is a simple and powerful circuit simulator. Perfect for students new to electronics circuit design and construction, hobbyists and tinkerers, and even seasoned professionals who want a quick, handy tool to perform electronics circuit design calculations.

It solves basic resistive circuits using Kirchoff’s Current Law (KCL) in much the same way a student in a circuits class would; the simulator systematically forms a matrix following KCL and then proceeds to solve for the unknown quantities using various algebraic techniques such as Gaussian elimination and sparse matrix techniques.

It offers the Trapezoidal(I'll add a GEAR method later) integration methods to approximate the state of the reactive elements. Although both methods will provide almost identical results for most circuits, it is generally regarded that the Gear method is more stable. Still, the trapezoidal method is faster and more accurate.

DroidTesla can simulate

  • Resistor
  • Capacitor
  • Inductor
  • Potentiometer
  • Light Bulb
  • Ideal operational amplifier
  • Bipolar junction transistor (NPN PNP)
  • MOSFET N-channel depletion
  • MOSFET N-channel enhancement
  • MOSFET P-channel depletion
  • MOSFET P-channel enhancement
  • JFET N and P
  • PN Diode
  • PN LED
  • PN Zener diode
  • AC source
  • DC source
  • AC voltage source
  • DC voltage(battery) source
  • CCVS - current-controlled voltage source
  • CCCS - current controlled current source
  • VCVS - voltage-controlled voltage source
  • VCCS - voltage-controlled current source
  • Square wave voltage source
  • Triangle wave voltage source
  • AC amperemeter
  • DC amperemeter
  • AC voltmeter
  • DC voltmeter
  • Two-channel oscilloscope
  • SPST Switch
  • SPDT Switch
  • Voltage-controlled switch
  • Current controlled switch
  • AND
  • NAND
  • OR
  • NOR
  • NOT
  • XOR
  • XNOR
  • JK flip-flop
  • 7 Segment Display
  • D flip-flop
  • Relay
  • IC 555
  • Transformer
  • Graetz Circuit
